Product thumbnail

114ft Streamlined Tug - 1/4" - Plans of Bridge Deck, House-Top, Boats, Thwartship Elevation and Separate Details of Deck Fittings Etc.

By Harold A. Underhill, A.M.I.E.S.

Price:
£10.50

Item attributes

ISBN:
n/a

Item details

Plan: 1188

Scale: ¼“

Length 28¼“ and displacement is 9.1lbs.

This vessel has many advantages as a working model, being low in build and therefore easy to transport, while the absence of the normal mast and rigging allows the superstructure to be made removable as a complete unit with nothing to be disconnected. It is a beautifully proportioned modern design. The hull lines are fine for this type of craft, which results in great flare at bow and stern in spite of the high beam-length ratio which is feature of all lugs.

The plans are very fully detailed - up to the exhibition standard - including all fittings on the arrangement drawing, with separate plans of each of the detail sheet as well as cross-sectional elevations of superstructure at several points along the hull.

Plans in this series: 1186  1187  1188

Alternative ³⁄₈” scale: 1183  1184  1185

Construction help: Plank-On-Frame Models Vol I  Plank-On-Frame Models Vol II

Catalogues: Sailing Ships  Powered Craft
